Brand Name : | Hengliang |
Model Number : | ZQS-40-SY |
Certification : | ISO |
Price : | USD 20000-35000/SET |
Payment Terms : | T/T |
Supply Ability : | 30 SET/Month |
Delivery Time : | 5~7days |
Weighing System Of Max 60T Quartz Load Cell & WIM Scales
(1) Pre inspect vehicles and screen overloaded vehicles.
(2) Monitor overloaded vehicles.
(3) Store vehicle data to provide data basis for management.
Product Parameters
Weighing accuracy | 90%~97% |
Single axle load | 40Ton |
Max Load | 60Ton |
Speed | 0.5~105km/h; |
Speed error | ≤±1km/h |
Wheelbase error | ≤±100mm |
Working voltage | AC 220V 50Hz |
Output information | Speed, total weight, axle load, axle number, wheelbase, vehicle type and passing time |
Maximum number of lanes | 8 lanes |
Data storage | It can store up to 10000 pieces of vehicle information data |
data interface | RJ485 |
work environment | -45℃~80℃,0~95% |
Confidence | ≥95% |
![]() |
